Manual screw jacks are slow and inconsistent. PLC-based systems can be expensive and overcomplicated. IMI Bimba delivered a smarter, simpler solution for a customer in the automotive industry assembling trailer axles.

The challenge? They needed a semi-automatic system to raise sub-assemblies to seven different heights, with a telescoping design that allowed greater travel than the overall cylinder length.

The Solution:
IMI Bimba engineered a cost-effective system using:

• TRD NFPA tie-rod cylinders to lower the unit below the conveyor
• Original Line® cylinders with stroke limiters and stop blocks for height control
• A single Mead directional control valve to operate the whole system

No PLCs. No extra programming. Just smart engineering.

The Result:

• 10% cost savings compared to electronically controlled positioning
• Lower maintenance and longer uptime
• Enhanced safety and better production yield

Ideal Applications:

• Automotive lift systems
• Palletizing and assembly lines
• Lift tables needing variable height positioning

Want to simplify your next automation project?

Contact Scott Equipment Company to learn how IMI Bimba solutions can improve your bottom line.
