X160N-SM Edco Surface Mount Base

Sku#: X160N-SM

Contact us for availability.
The Edco X160N-SM surface mount base has a capacity of 160 cfm (Cubic Feet per Minute). Seals are made of Nitrile and comes with a standard gauge orientation.

The Edco SM (surface mount) base for classic series vacuum pumps includes 1/2” vacuum ports at three locations and a flat backside for panel mounting. One to
three vacuum lines can be ran directly from the pump base. Unused vacuum ports simply need to be plugged. This design
makes this pump configuration ideal for robotic end-effectors.

Edco Surface Mount Base Specifications
