VM151-N01-35BA SMC 2/3 Port Mechanical Valve

Sku#: VM151-N01-35BA

Contact us for availability.
The SMC VM151-N01-35BA is a 2/3 port mechanical valve. It has 5 ports (twisted selector, 3 position only) and 1 side port. The body uses side mounting and has a NPT 1/8" port size. The actuator is a twist selector with 3 positions.

The new SMC VM100/200 2/3 port mechanical valve series is now more lightweight and compact than the conventional model. The VM100/200 series has a variety of actuator types to choose from.  Also, with piping options of side ported and bottom ported, it is now possible to choose the mounting method with the side ported.

  • Fluid: air
  • Compact size
  • Piping: side ported, bottom ported
  • Possible to choose mounting method with side ported
  • Variety of actuator types

SMC VM1000 Series How to Order
