Delta Power Company 2-Way Valve TT-S2D-00

DESCRIPTION: 12 size, 1 1/16-12 thread, “Tecnord” series, solenoid operated, 2 way normally open, pilot operated poppet valve with free reverse flow energized and de-energized.

OPERATION:  When de-energized the TT-S2D allows flow to pass from (1) to (2) and (2) to (1). When energized the valve blocks flow from (1) to (2) but allows free reverse flow from (2) to (1).
OPERATION OF MANUAL OVERRIDE OPTION: to override, turn the manual override screw clockwise.
To release turn the manual override screw counterclockwise.

FEATURES:

•    Hardened parts for long life.
•    Efficient wet-armature construction.
•    Cartridges are voltage interchangeable.
•    Manual override option.
•    Industry common cavity.
•    Unitized, molded coil design.
•    Continuous duty rated solenoid.
•    Optional coil voltages and terminations.
•    Optional “I” Coil: Weatherproof, Thermal Shock, Immersion Safe.
