TD-4200-R Alkon Corporation Trans-DOT 3/2 Push-Pull Manual Valve, Red Knob
Sku#: TD-4200-R
Contact us for availability.
Details
More Information
Reviews
Alkon Corporation TD-4200-R valves are 3-way, 1/4" NPT, 3-ported, 2-position, push-pull valves detented in both positions, fitted with a red mushroom knob. Air is normally supplied to port #1 but can also be supplied to port #3.
Specifications
| Material | Black anodized aluminum, urethane seals | Temperature | -40F to +180F |
| Function | 3/2 push-pull, detented | Knob | Red mushroom, 1.81" dia. |
| Mounting | Panel mount, Inline, or Thru hole mount | Panel Mount | 7/8-14 thread, 1-1/4" hex nut |
| Medium | Air | ||
| Pressure | 200 psi max. supply | ||
| Flow | Cv = 1.0 (48 scfm fully open) | ||
| Fasteners | Stainless steel |
