KQ2Y23-M3G SMC KQ2 One-Touch Fitting - Male Run Tee, 3.2 mm OD Tube x M3 Male

The SMC KQ2Y23-M3G is a KQ2 series male run tee. It connects 3.2 mm OD tubing to an M3 x 0.5 male thread. Use to connect two tubes to one female thread, with one tube in line with the thread and one at 90 degrees.

303 stainless steel body. Round type release button. Operating pressure: 29.5 inHg vacuum to 1 MPa (145 psi).
