KQ2U10-00A-X35 SMC KQ2 One-Touch Fitting - Union "Y", 10 mm OD Tube

The SMC KQ2U10-00A-X35 is a KQ2 series union "Y". It connects 10 mm OD tubing. Use to join three tubes of the same size, with two branching in the same direction.

Brass body. Round type release button. Black body with a light gray release button. Operating pressure: 29.5 inHg vacuum to 1 MPa (145 psi).
