KQ2U02-00A SMC KQ2 One-Touch Fitting - Union "Y", 2 mm OD Tube

The SMC KQ2U02-00A is a KQ2 series union "Y". It connects 2 mm OD tubing. Use to join three tubes of the same size, with two branching in the same direction.

Brass body. Round type release button. Operating pressure: 29.5 inHg vacuum to 1 MPa (145 psi).
