KQ2L16-03AP SMC KQ2 One-Touch Fitting - Male Elbow, 16 mm OD Tube x R3/8 Male

The SMC KQ2L16-03AP is a KQ2 series male elbow. It connects 16 mm OD tubing to an R3/8 male thread. Use to connect a tube to a female thread at a 90 degree angle.

Brass body. Face seal type. Round type release button. Operating pressure: 29.5 inHg vacuum to 1 MPa (145 psi).
