KQ2L08-12A-X12 SMC KQ2 One-Touch Fitting - Reducer Elbow, 8 mm to 12 mm OD Tube

The SMC KQ2L08-12A-X12 is a KQ2 series reducer elbow. It connects 8 mm OD tubing to 12 mm OD tubing. Use to join two tubes of different sizes at a 90 degree angle.

Brass body. Round type release button. White vaseline lubricant with a white release button. Operating pressure: 29.5 inHg vacuum to 1 MPa (145 psi).
