KQ2L05-07A SMC KQ2 One-Touch Fitting - Reducer Elbow, 3/16 in to 1/4 in OD Tube

The SMC KQ2L05-07A is a KQ2 series reducer elbow. It connects 3/16 in OD tubing to 1/4 in OD tubing. Use to join two tubes of different sizes at a 90 degree angle.

Brass body. Round type release button. Operating pressure: 29.5 inHg vacuum to 1 MPa (145 psi).
