KQ2F12-G04N SMC KQ2 One-Touch Fitting - Female Connector, 12 mm OD Tube x G 1/2 Female

Sku#: KQ2F12-G04N

Contact us for availability.
SMC KQ2 female connector. Connects 12 mm OD tubing to a G 1/2 female thread. Nickel-plated brass.

The SMC KQ2F12-G04N is a KQ2 series female connector. It connects 12 mm OD tubing to a G 1/2 female thread. Use to connect a tube to a male thread with a straight connection.

Nickel-plated brass body. Round type release button. Operating pressure: 29.5 inHg vacuum to 1 MPa (145 psi).
