KQ2F08-G03N SMC KQ2 One-Touch Fitting - Female Connector, 8 mm OD Tube x G 3/8 Female

Sku#: KQ2F08-G03N

Contact us for availability.
SMC KQ2 female connector. Connects 8 mm OD tubing to a G 3/8 female thread. Nickel-plated brass.

The SMC KQ2F08-G03N is a KQ2 series female connector. It connects 8 mm OD tubing to a G 3/8 female thread. Use to connect a tube to a male thread with a straight connection.

Nickel-plated brass body. Round type release button. Operating pressure: 29.5 inHg vacuum to 1 MPa (145 psi).
