KED-CONKIT-MV12 Kollmorgen Essentials Connector Kit

The Kollmorgen Essentials KED-CONKIT-MV12 Connector Kit is an OEM drive-side connector and termination kit designed for use with Kollmorgen hybrid servo cables in KED-series servo drive installations. This kit provides the proper interface components required to securely terminate hybrid motor cables that carry motor power, brake wiring, and SFD-M/SFD3 absolute feedback signals.



Engineered for seamless integration with the Kollmorgen Essentials motion platform, the MV12 connector kit ensures reliable mechanical support, consistent cable strain relief, and proper electrical termination at the servo drive. These factors are critical for maintaining servo performance, achieving clean encoder feedback, and preventing electrical noise issues in demanding industrial automation environments.



The KED-CONKIT-MV12 is ideal for OEMs, machine builders, panel fabricators, and maintenance technicians who need a factory-approved connector solution for Essentials hybrid cables. Supplied with the required connector body and termination components, it enables fast, repeatable, and EMC-compliant cable assembly.



This connector kit is recommended any time a new hybrid cable is installed, a drive is replaced, or a field repair requires re-terminating a servo cable. As an authentic Kollmorgen component, it guarantees compatibility and long-term reliability for KED-series drive systems.



Key Technical Specifications
