KED-CON-X3-MV12 Kollmorgen Essentials Mating Connector X3

The Kollmorgen Essentials KED-CON-X3-MV12 Mating Connector is an OEM motor-side connector designed for terminating MV12 hybrid servo cables used in Kollmorgen Essentials motion systems. This connector provides the proper mechanical and electrical interface required to mate a hybrid cable—carrying motor power, brake control lines, and SFD-M / SFD3 absolute feedback signals—directly to a Kollmorgen servo motor.



As part of the Kollmorgen Essentials ecosystem, the X3-MV12 connector ensures secure engagement, stable signal integrity, and approved EMC-safe shield termination, all of which are essential for reliable servo performance in industrial automation environments. It preserves cable grounding integrity, reduces electrical noise, and supports the precise communication required for high-resolution absolute feedback devices.



The KED-CON-X3-MV12 is ideal for OEM machine builders, wiring harness fabricators, control-panel integrators, and maintenance technicians assembling or replacing hybrid motor cables. As an official Kollmorgen mating connector, it guarantees proper fitment with MV12 cable assemblies and ensures long-term connection stability even under vibration, thermal cycling, and continuous machine operation.



Whether used in new installations or field repairs, this motor-side MV12 mating connector ensures that Kollmorgen Essentials servo motors receive clean power, accurate feedback, and dependable wiring integrity.
