K-B-EF-25 Bimba EF1 Repair Kit
Sku#: K-B-EF-25
Contact us for availability.
Details
More Information
Reviews
Bimba EF1 cylinders are repairable. To order repair kits, please provide the correct bore code in the
kit part number blank for the desired size repair kit. Optional seals are designated by the suffix option.
Repair kits include the standard bronze rod bushing, piston, rod, and body seals.*
| Part # | Description | Material |
| 1 | Rod | 4301 (303) Stainless Steel |
| 2 | Rod Seal/Wiper | Nitrile (Standard) or Fluoroelastomer (High Temperature Option) |
| 3 | Reatining Ring | Zinc Plated Carbon Steel or Stainless Steel (optional) |
| 4 | Rod Guide | 12-20mm: Bronze / 25-100mm: Anodized Aluminum |
| 5 | Bushing | 12-20mm: Bronze / 25-100mm: Self Lubricating Nylon |
| 6 | Piston Seal | 12-20mm: Bronze / 25-100mm: Self Lubricating Nylon |
| 7 | Cylinder Body | Polytetrafluoroethylene (PTFE) Impregnated Hard Anodized Aluminum |
| 8 | Rod Guide Seal | Nitrile (Standard) or Fluoroelastomer (High Temperature Option) |
| 9 | Piston | High Strength Aluminum Alloy |
| 10 | Spring | Corrosion Protected Music Wire |
| Part # | Description |
| K-B-EF-[Bore] | EF Series Repair Kit |
| K-B-EFD-[Bore] | EFD Series Repair Kit |
| K-B-EF-[Bore-]V | EF Series Repair Kit with FKM High Temperature Seals |
| NOTE: Replace [Bore] in the part number with the appropriate bore size indicator. | |
