H2-51-015-A5-00-009000 Kollmorgen Essentials Motor & Drive Cable - 9 Meter

The Kollmorgen Essentials H2-51-015-A5-00-009000 is a 9-meter hybrid servo cable designed for use with Kollmorgen’s Essentials servo motors and KED-series servo drives. Part of the H2 Mid-flex PUR hybrid cable family, this assembly integrates motor power, brake conductors, and SFD-M/SFD3 absolute feedback pairs into a single, shielded, industrial-grade cable—reducing wiring complexity and boosting reliability in electrically noisy environments.



Constructed with 1.5 mm² power conductors, a rugged PUR outer jacket, and high-quality shielding, this cable is rated for 1000 V, excellent oil resistance, and a flex life of more than 12 million cycles, making it ideal for dynamic, continuous-motion applications. The motor-end connector uses the A5 M23 SpeedTec interface, ensuring perfect compatibility with Kollmorgen KEM, AKM, and AKM2G motors using SFD-M or SFD3 feedback.



Connector type 51 designates compatibility with KED-SPM-6V03S and KED-SPM-6V06S servo drives. Inside the hybrid assembly, the cable carries three motor phase conductors (U/V/W), brake wiring, protective earth, and differential absolute encoder communication—delivering robust EMC performance and clean feedback signals.



The length code 009000 indicates a 9-meter (9000 mm) cable. The construction meets strict industrial standards including UL/ULC, CE, NFPA 79, CEI 20-35 flame resistance, and is oil-resistant, silicone-free, lead-free, and clean-room compliant.



Durable, flexible, and fully shielded, the H2-51-015-A5-00-009000 is the ideal 9-meter hybrid cable solution for Kollmorgen Essentials motion systems.



Key Technical Specifications
