H2-51-015-A5-00-006000 Kollmorgen Essentials Motor & Drive Cable - 6 Meter
Sku#: H2-51-015-A5-00-006000
The Kollmorgen Essentials H2-51-015-A5-00-006000 is a 6-meter hybrid servo cable engineered for use with Kollmorgen Essentials motors and KED-series servo drives. Part of the H2 Mid-flex PUR cable family, this cable integrates motor power, brake wiring, and absolute feedback communication into a single, shielded hybrid assembly—simplifying installation and ensuring long-term reliability in industrial environments.
Constructed with 1.5 mm² power conductors, high-quality shielding, and a long-life PUR outer jacket, the cable supports a 1000 V rating, offers excellent oil resistance, and is designed for dynamic motion applications with a flex life exceeding 12 million cycles. The motor-side A5 M23 SpeedTec connector ensures drop-in compatibility with KEM, AKM, and AKM2G motors equipped with SFD-M or SFD3 feedback.
Connector type 51 ensures proper drive-side connection to KED-SPM-6V03S and KED-SPM-6V06S servo drives. The hybrid layout includes three motor phases (U/V/W), brake leads, protective earth, and differential SFD feedback pairs—providing excellent EMI performance and minimizing cable bulk inside the machine.
The 006000 length code designates this cable as 6 meters (6000 mm). The assembly is certified to UL/ULC, CE, NFPA 79, is oil-resistant, clean-room compatible, silicone-free, and meets CEI 20-35 flame resistance requirements.
Engineered for demanding servo applications, the H2-51-015-A5-00-006000 provides a durable, plug-and-play solution for Kollmorgen Essentials motion systems.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | H2-51-015-A5-00-006000 |
| Cable Family | H2 Mid-flex Hybrid PUR (motor + brake + feedback) |
| Drive Compatibility | KED-SPM-6V03S, KED-SPM-6V06S |
| Motor Connector Type | A5 — M23 SpeedTec |
| Power Conductor Size | 1.5 mm² |
| Cable Outer Diameter | 13.2 mm |
| Minimum Bend Radius (Static) | 66 mm |
| Minimum Bend Radius (Dynamic) | 92.4 mm |
| Length | 6 meters |
| Weight | 2.40 kg (5.29 lb) (0.40 kg per meter × 6) |
| Voltage Rating | 1000 V |
| Temperature Rating | −40°C to +90°C (flexing) |
| Flex Life | 12,000,000 cycles |
| Certifications | CE, UL/ULC, NFPA 79, CEI 20-35 flame resistant, oil-resistant, silicone-free, clean-room approved |
