H2-51-015-A5-00-003000 Kollmorgen Essentials Motor & Drive Cable - 3 Meter
Sku#: H2-51-015-A5-00-003000
The Kollmorgen Essentials H2-51-015-A5-00-003000 is a 3-meter hybrid servo cable engineered specifically for Kollmorgen Essentials servo systems. As part of the H2 Mid-flex PUR cable family, this all-in-one cable provides motor power, brake wiring, and high-integrity SFD-M/SFD3 absolute encoder feedback through a single, fully shielded assembly—reducing wiring complexity and improving reliability.
The cable uses 1.5 mm² power conductors and a rugged PUR outer jacket designed for industrial environments, rated for 1000 V, excellent oil resistance, and a dynamic flex life exceeding 12 million cycles. The motor-side connector features the A5 M23 SpeedTec interface, ensuring seamless compatibility with Kollmorgen KEM, AKM, and AKM2G servo motors.
Drive-side connector type 51 ensures correct fit with KED-SPM-6V03S and KED-SPM-6V06S Essentials servo drives. The hybrid construction carries motor phases (U/V/W), brake conductors, protective earth, and differential SFD feedback pairs—maintaining robust signal integrity even in electrically noisy applications.
The 003000 length code identifies this cable as 3 meters, following Kollmorgen’s mm-based standard (xxxx00 = length in mm). It is certified for use in demanding environments, meeting UL/ULC, CE, NFPA 79, CEI 20-35 flame resistance, and is lead-free, silicone-free, oil-resistant, and clean-room compatible.
Built for durability, EMC performance, and drop-in compatibility with Kollmorgen Essentials drives and motors, this cable is the recommended 3-meter hybrid solution for single-cable servo installations.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | H2-51-015-A5-00-003000 |
| Cable Family | H2 Mid-flex Hybrid PUR (motor + brake + feedback) |
| Drive Compatibility | KED-SPM-6V03S, KED-SPM-6V06S |
| Motor Connector Type | A5 — M23 SpeedTec |
| Power Conductor Size | 1.5 mm² |
| Cable Outer Diameter | 13.2 mm |
| Minimum Bend Radius (Static) | 66 mm |
| Minimum Bend Radius (Dynamic) | 92.4 mm |
| Length | 3 meters |
| Weight | 1.20 kg (2.65 lb) (0.40 kg per meter × 3) |
| Voltage Rating | 1000 V |
| Temperature Rating | −40°C to +90°C (flexing) |
| Flex Life | 12,000,000 cycles |
| Certifications | CE, UL/ULC, NFPA 79, CEI 20-35 flame resistant, oil-resistant, silicone-free, clean-room approved |
