DF-S3A-00 Delta Power Company Direct Acting Spool
Sku#: DF-S3A-00
Contact us for availability.
Details
Resources
More Information
Reviews
DESCRIPTION:
10 Size, 7/8-14 trhead, "Delta" series, solenoid operated, 3 way 2 position, spool valve.
OPERATION:
When de-energized the DF-S3A allows flow from (3) to (2) and blocks flow at Port (1). When energized the valve allows flow from (1) to (3) and block flow at port (2).
OPERATION OF MANUAL OVERRIDE OPTION: to override, pull knob out. On the detented version, after pulling knob out twist 180 degrees and release. The valve will remain in that position.
FEATURES:
- Hardened parts for long life.
- Efficient wet-armature construction.
- Cartridges are voltage interchangeable.
- Manual override option.
- Industry common cavity.
- Unitized, molded coil design.
- Continuous duty rated solenoid.
- Optional coil voltages and terminations.
- Optional 'I" Coil: Weatherproof, Thermal Shock, Immersion Safe.
OPTIONS
| Buna Standard | 00 |
| Viton Standard | V0 |
| Buna, Override, Detent | 0M |
| Viton, Override, Detent | VM |
| Buna, Screen | A0 |
| Viton, Screen | W0 |
| Buna, Override, Nondetent | B1 |
| Viton, Override, Nondetent | V1 |
| Buna, Screen, Override, Nondetent | B3 |
| Viton, Screen, Override, Nondetent | V3 |
| Buna, Screen, Override, Detent | B4 |
| Viton, Screen, Override, Detent | V4 |
