DE-S2I-00 Delta Power Company Direct Acting Poppet Valve
Sku#: DE-S2I-00
DESCRIPTION
10 size, 7/8-14 thread, “Delta” series, solenoid operated, 2 way normally closed, bidirectional poppet valve.
OPERATION
When de-energized the DE-S2I blocks flow from (1) to (2) and (2) to (1). When energized the valve allows flow
from (1) to (2) and (2) to (1).
OPERATION OF MANUAL OVERRIDE OPTION: to override, turn the manual override screw clockwise. To
release turn the manual override screw counter-clockwise.
FEATURES
• Hardened parts for long life.
• Efficient wet-armature construction.
• Cartridges are voltage interchangeable.
• Manual override option.
• Industry common cavity.
• Unitized, molded coil design.
• Continuous duty rated solenoid.
• Optional coil voltages and terminations.
• Optional “I” Coil: Weatherproof, Thermal Shock, Immersion Safe.
| VALVE SPECIFICATIONS | |
| Nominal Flow | 3 GPM (11 LPM |
| Rated Operating Pressure | 3000 PSI (207 bar) |
| Typical Internal Leakage (150 SSU) | 0-10 drops/min |
| Viscosity Range | 36 to 3000 SSU (3 to 647 cSt) |
| Filtration | ISO 18/16/13 |
| Media Operating Temp. Range | -40° to 250°F (-40° to 120°C) |
| Weight | 21 lbs (.09 kg) |
| Operating Fluid Media | General Purpose Hydraulic Fluid |
| Cartridge Torque Requirements | 30 ft-lbs (406 Nm) |
| Coil Nut Torque Requirements | 406 ft-lbs (5.4-8.1 Nm) |
| Cavity | DELTA 2W |
| Cavity Tools Kit (form tool, reamer, tap) | 40500000 |
| Seal Kit | 21191202 |
