DE-S2G-00 Delta Power Company Direct Acting Spool
Sku#: DE-S2G-00
DESCRIPTION
10 size, 7/8-14 thread, “Delta” series, solenoid operated, 2 way normally closed, spool valve.
OPERATION
When de-energized the DE-S2G blocks flow from (1) to (2) and (2) to (1). When energized the valve allows flow
from (1) to (2) and (2) to (1).
OPERATION OF MANUAL OVERRIDE OPTION: to override, pull knob out. On the detented version, after
pulling knob out twist 180 degrees and release. The valve will remain in that position.
FEATURES
• Hardened parts for long life.
• Efficient wet-armature construction.
• Cartridges are voltage interchangeable.
• Manual override option.
• Industry common cavity.
• Unitized, molded coil design.
• Continuous duty rated solenoid.
• Optional coil voltages and terminations.
• Optional “I” Coil: Weatherproof, Thermal Shock, Immersion Safe.
Valve Specifications
| Nominal Flow | 8 GPM (30 LPM) from (1) to (2) 5 GPM (19 LPM) from (2) to (1) |
| Rated Operating Pressure | 3000 PSI (207 bar) |
| Typical Internal Leakage | (150 SSU) 5 cu in/min (82 ml/min) |
| Viscosity Range | 36 to 3000 SSU (3 to 647 cSt) |
| Filtration | ISO 18/16/13 |
| Media Operating Temp. Range | -40° to 250°F (-40° to 120°C) |
| Weight | .26 lbs (.12 kg) |
| Operating Fluid Media | General Purpose Hydraulic Fluid |
| Cartridge Torque Requirements | 30 ft-lbs (40.6 Nm) |
| Coil Nut Torque Requirements | 4-6 ft-lbs (5.4-8.1 Nm) |
| Cavity | DELTA 2W |
| Cavity Tools Kit (form tool, reamer, tap) |
40500000 |
| Seal Kit | 21191202 |
