D6C0MC NGT 3/8 NPTF Dual Pneumatic Valve to Prevent Runaway Movement, Manual Release
Sku#: D6C0MC
Contact us for availability.
Details
More Information
Reviews
The NGT D6C0MC is a 3/8 NPTF dual pneumatic valve to prevent runaway movement with a manual release.
Basic Operation:
This valve is used to reduce jerky motion in pneumatic systems. Back pressure is constantly applied to the air cylinder piston in order to prevent a runaway condition, where the cylinder will take off quickly and then stop when the back pressure builds up enough pressure to stop cylinder movement.
- Dual Manual Release
- .0000522 cc/min Leak Rate
- Applies Constant Back Pressure to One Side of the Cylinder
- Prevents Runaway Condition
Operating Data:
| Max. Pressure: | 150 psi |
| Min. Pilot Pressure: | 40 psi |
| Counterbalance: | The counterbalance should be on the load side where gravity is adding to the pressure |
| Temperature Range: | -20 - 150 F |
| Cycle Rate: | 1 cyc./sec. max. |
| Flow Capacity (Cv): | 3.8 |
| Cracking Pressure: | 1 - 2 psi (floating check) |
| Service: | Properly filtered dry air or lubricated air |
Available Models:
| Model No. | Manual Release | Flush Manual Release |
|---|---|---|
| 3/8 NPTF | D6C0MC | D6CFMC |
