B4M0MSS-V NGT 1/4 NPTF 316 Stainless Steel Balanced Pilot Operated Check Valve, Manual Release, High Temp Seals
Sku#: B4M0MSS-V
Contact us for availability.
Details
More Information
Reviews
The NGT B4M0MSS-V is a 1/4 NPTF 316 stainless steel balanced pilot operated check valve with a manual release and high-temperature seals (to 350 F).
Basic Operation:
Lock your pneumatic device in position when a pressure drop or total loss of pressure occurs. Manual release for exhausting trapped air before maintaining the system (OSHA Requirement).
- 316 Stainless Steel Body
- Immediate Checking
- Optional Manual Release
- .0000522 cc/min Leak Rate
- Low & High Temp
Operating Data:
| Max. Pressure: | 150 psi |
| Min. Pilot Pressure: | 40 psi |
| Leak Rate: | .0000522 cc/min |
| Temperature Range: | 30 - 350 F (-V high temp seals) |
| Cycle Rate: | 1 cyc./sec. max. |
| Flow Capacity (Cv): | 2.6 |
| Cracking Pressure: | 1 - 2 psi |
| Service: | Properly filtered dry air or lubricated air |
Available Models:
| Model No. | No Manual Release | Manual Release | Flush Manual Release |
|---|---|---|---|
| 1/4 NPTF | B4M00SS | B4M0MSS | B4MFMSS |
| 3/8 NPTF | B6M00SS | B6M0MSS | B6MFMSS |
| For high temp seals add (-V) to the model # (ex. B4M0MSS-V). For low temp seals add (-T40) to the model # (ex. B4M0MSS-T40). |
|||
