B4M0M-AD NGT 1/4 NPTF Adjustable Pilot-Operated Check Valve, Manual Release
Sku#: B4M0M-AD
Contact us for availability.
Details
More Information
Reviews
The NGT B4M0M-AD is a 1/4 NPTF adjustable pilot-operated check valve with a manual release.
Basic Operation:
Locks any pneumatic device in position when a pressure drop or total loss of pressure occurs. Set the valve to close at a certain pressure: the pilot line reads the pressure and closes the valve when it drops below the set pressure, for faster stops.
- Adjustable Pilot Pressure
- Faster Stops
- .0000522 cc/min Leak Rate
- Manual Release Option
Operating Data:
| Max. Pressure: | 120 psi |
| Min. Pilot Pressure: | Adjustable |
| Leak Rate: | .0000522 cc/min |
| Temperature Range: | 30 - 150 F |
| Cycle Rate: | 1 cyc./sec. |
| Flow Capacity (Cv): | 2.6 |
| Cracking Pressure: | 1 - 2 psi |
| Service: | Properly filtered dry air or lubricated air |
Available Models:
| Model No. | No Manual Release | Manual Release | Flush Manual Release |
|---|---|---|---|
| 1/8 NPTF | B2M00AD | B2M0MAD | B2MFMAD |
| 1/4 NPTF | B4M00AD | B4M0MAD | B4MFMAD |
| 3/8 NPTF | B6M00AD | B6M0MAD | B6MFMAD |
| 1/4 BSPP | BG4M00AD-1 | BG4M0MAD-1 | BG4MFMAD-1 |
| 3/8 BSPP | BG6M00AD | BG6M0MAD | BG6MFMAD |
