B1210MFL NGT 3/4 NPTF Balanced Pilot Operated Check Valve with Flow Control, Manual Release
Sku#: B1210MFL
Contact us for availability.
Details
More Information
Reviews
The NGT B1210MFL is a 3/4 NPTF balanced pilot operated check valve with flow control and a manual release.
Basic Operation:
Hold position when a pressure drop or total loss of pressure occurs. The flow control meters air from the output to the input port for fast advance and slow retract, avoiding crash landings. Manual release to exhaust trapped air before maintaining the system (OSHA Requirement).
- Lower Loads Slowly
- Optional Manual Release
- .0000522 cc/min Leak Rate
Operating Data:
| Max. Pressure: | 150 psi |
| Min. Pilot Pressure: | 40 psi |
| Temperature Range: | 30 - 150 F |
| Cycle Rate: | 1 cyc./sec. max. |
| Flow Capacity (Cv): | 3.8 max. |
| Cracking Pressure: | 1 - 2 psi |
| Service: | Properly filtered dry air or lubricated air |
Available Models:
| Model No. | No Manual Release | Manual Release | Flush Manual Release |
|---|---|---|---|
| 1/2 NPTF | B8100FL | B810MFL | B81FMFL |
| 3/4 NPTF | B12100FL | B1210MFL | B121FMFL |
| For a lower pilot pressure add (-K18) to the model # (ex. B810MFL-K18). | |||
