A715477005 Enidine Viscous Speed Governor, 1 in Shaft with 1/4 in Keyway, 5,000 cSt Silicone

The Enidine A715477005 is a viscous speed governor, 1 in Shaft with 1/4 in Keyway, 5,000 cSt Silicone.

An Enidine viscous speed governor (VSG) controls the rotation of shafts and hinged loads using silicone-based viscous shearing: as the shaft turns, an inner rotor shears the silicone fluid inside the stationary housing, giving resistance and smooth motion control. Fluid viscosity is selected for the component size, weight, spring assist and desired cycle time. Enidine states the VSG controls rotary motion in both directions through 360 degrees, needs no adjustment and operates from -40 °F to +200 °F (-40 °C to +95 °C).

Specifications:

Manufacturer:	Enidine
Model:	VSG 1X 1/4 KW 5,000 CST SILICONE
Enidine part number:	A715477005
Series:	VSG
Type:	Viscous speed governor

Source: Enidine 2026 price list; enidine.com, Viscous Speed Governor.
