A6M0MFL NGT 3/8 NPTF Pilot-Operated Locking Valve with Flow Control, Manual Release
Sku#: A6M0MFL
Contact us for availability.
Details
More Information
Reviews
The NGT A6M0MFL is a 3/8 NPTF pilot-operated locking valve with flow control and a manual release.
Basic Operation:
Lock your pneumatic device in position when a pressure drop or total loss of pressure occurs. Slowly lower the load when the valve is piloted open. The manual release for exhausting trapped air is also metered through the flow control, so the load is lowered slowly when the manual release is depressed.
- Manual Release (Metered)
- .000113 cc/min Leak Rate
- Lower Loads Slowly
Operating Data:
| Max. Pressure: | 120 psi |
| Min. Pilot Pressure: | 30 psi @ 80 psi |
| Leak Rate: | .000113 cc/min |
| Temperature Range: | 30 - 150 F |
| Cycle Rate: | 1 cyc./sec. max. |
| Flow Capacity (Cv): | 1.2 |
| Cracking Pressure: | 2 - 3 psi |
| Service: | Properly filtered dry air or lubricated air |
Available Models:
| Model No. | Manual Release |
|---|---|
| 1/4 NPTF | A4M0MFL |
| 3/8 NPTF | A6M0MFL |
