33SAYM Baco 130 V Yellow LED Screw Terminal Base Mount Block

The Baco 33SAYM is a 130 V Yellow LED Screw Terminal Base Mount Block.

Base mounts directly into empty Baco LBX control stations — no mounting clip required.

• Long-life LED; match the module voltage to your control circuit

Specifications:

Manufacturer:	Baco Controls
Part Number:	33SAYM
Device Type:	LED Module
Size:	22 mm
Terminal Type:	Screw Terminal
Configuration:	Component
Color:	Yellow
LED Voltage:	130 V AC
Mounting:	Base mount (for empty LBX control stations, no clip)

General Specifications:

Rated insulation voltage:	300 V
Current consumption:	20 mA ± 10%
LED lifetime:	100,000 hours at 25 °C
Operating temperature:	-25 °C to +70 °C

Source: Baco Controls catalog 803, technical specifications.
